技术规格
扇叶数量(Number of airfoils) | 6片 Six patented airfoils |
扇叶表面处理(Airfoil finish) | 喷砂阳极氧化处理 Sand blasting and anodic oxidation treatment |
驱动设备(Motor) | 原装进口德国伦茨或意大利邦飞利电机,绝缘等级F,大扭矩 Original imoprted Germany Lenze or Italian Bonfiglioli motor, F insulation levels,high pulling torque. |
功 率 (Power) | 0.75 KW |
额定电压 (Voltage rating) | 400/230V |
满载电流 (Full-road current) | 1.8/3.1A |
吊装重量 (Weight) | 87KG |
转速 (Rotate speed) | 0-85RPM |
风 速 (Air speed) | 约0~4.3 m/s Around 0~4.3 m/s |
风 量 (Displacement) | 6000CMM |
最大扩散面积 (Max diffusion area) | 1000M2 |
